Rolling IV Stands
An extensive portfolio of configurations and features that can help meet your requirements.
Brushed stainless steel construction 1
Rake top 2
Telescoping, slow descending inner pole 3
Heavy duty base 4
Can help reduce the likelihood of IV stand tipping or becoming top-heavy.
Premium rubber casters 5
with sealed stainless steel ball bearings moves easily and quietly that can help make patient transport smooth.
Caution
- It is recommended that the device is thoroughly wiped with a damp towel and a mild cleaning solution once a week or more often, as needed. Cleaning solutions may be corrosive to this device. Not MRI Compatible.
- Maximum hook top load is 8.8 lbs (4 kg).
- Adjust upper pole to lowest possible position during transit.
- Do not overload this stand to create an unstable condition.
- Use caution when rolling over elevator thresholds and other uneven surfaces.
RD-0710A3G for up to 3 Infusion Pumps
- Single pole, five-legged detachable heavyweight base, 22-inch diameter with sky-white epoxy finish
- One stainless steel 8-hook top
- Pole is 68 inches compressed, 99 inches fully extended
- Available patient support handle (RD-728)
RD-0710B for up to 4 Infusion Pumps
- Single-pole, six-legged heavyweight base, 25-inch diameter with sky-white epoxy finish
- Mounting platform
- One stainless steel 8-hook top
- Pole is 68 inches compressed, 96 inches fully extended
- Available patient support handle (RD-728)
RD-09003G for up to 12 Infusion Pumps
- Tri-pole, six-legged safety series base, 27-inch diameter with sky-white epoxy finish
- Two medical grade power strips with six outlets each with protective cover and cord wraps
- Painted steel handle
- Three stainless steel 4-hook tops for each pole
- Poles are 71.5 inches compressed, 99 inches fully extended
RD-09103G for up to 8 Infusion Pumps
- Dual-pole, six-legged safety series base, 25-inch diameter with sky-white epoxy finish
- Two medical grade power strips with four outlets each with protective cover and cord wraps
- Painted steel handle
- Two stainless steel 6-hook tops for each pole
- Poles are 73.12 inches compressed, 99 inches fully extended
RD-0711US for up to 8 Infusion Pumps
- Dual-pole, six-legged heavyweight base, 25-inch diameter with sky-white epoxy finish
- One medical grade power strips with four outlets each with protective cover and cord wraps
- Patient support handle with utility tray
- CenterG off-set stainless steel pump adapter with 2 slow descending inner poles
- Platform to rest instruments on during attachment
- Two stainless steel 8-hook tops for each pole
- Pole is 66 inches compressed, 76 inches fully extended
RD-0713 for up to 8 Infusion Pumps
- Single-pole six-legged heavyweight base, 25-inch diameter with sky-white epoxy finish
- Painted steel patient support handle
- CenterG off-set stainless steel pole mount with slow descending inner pole
- One stainless steel 8-hook rake top, one 4-hook stainless steel side hook
- Mounting shelf
- Pole is 71.5 inches compressed, 82.5 inches fully extended
Product Comparison Chart
| RD-0710A3G | RD-0710B | RD-09003G | RD-09103G | RD-0711US | RD-0713 | |
|---|---|---|---|---|---|---|
| Maximum # of Infusion Pumps | 3 | 4 | 12 | 8 | 8 | 8 |
| # of Poles | 1 | 1 | 3 | 2 | 2 | 1 |
| # of Hooks | 8 | 8 | 12 (4 per pole) |
12 (6 per pole) |
16 (8 per pole) |
8 with 4 slide |
| # of Legs/Wheels | 5 | 6 | 6 | 6 | 6 | 6 |
| Power Strips / Outlets | No | No | 2 Power Strips 6 outlets per |
2 Power Strips 4 outlets per |
1 Power Strip 4 outlets |
No |
| Painted Steel Handle | No | No | Yes | Yes | Yes, with utility tray | Yes |
| Height | 68″ to 99″ | 68″ to 96″ | 71.5″ to 99″ | 73.12″ to 99″ | 66″ to 76″ | 71.5″ to 82.5″ |
Power Strip Compliance1
The CMS guidelines titled, “Categorical Waiver for Power Strips Use in Patient Care Areas” by Center for Clinical Standards and Quality/Survey & Certification Group (CMS), dated September 26, 2014 state, “CMS is permitting a categorical waiver to allow for the use of power strips in existing and new health care facility patient care areas, if the provider/supplier is in compliance with all applicable 2012 LSC power strip requirements and with all other 2000 LSC electrical system and equipment provisions.” Our power strips not only meet but exceed the provisions set forth in the 2012 Life Safety Code (LSC). As a result, our power strips qualify for the Categorical Waiver as per the CMS Guidelines.
The guidelines also mention, “The sum of the ampacity of all appliances connected to the receptacles shall not exceed 75 percent of the ampacity of the flexible cord supplying the receptacles.” Our power strips are rated at 15 amps each. Maximum current draw of our pumps is as follows: Ivenix Infusion System: 0.84A and Agilia Connect Volumetric Pump and Syringe Pump: 0.15A. Even when 6 devices are connected to the power strip, our maximum current draw is 5.04A, significantly below 11.25A, the 75% amperage threshold for power strips with our devices.
1. CMS Center for Clinical Standards and Quality/Survey & Certification Group; 2014 Ref S&C:14-46-LSC.
Rolling IV Stand Accessory
RD-0951 Horizontal Ivenix Pump Carrier for 3 Ivenix Infusion Pumps
- Tri-pole pump carrier with clamp opening adjusts from 0” to 1-3/8” using speed clamp technology
- One medical grade power strip with four outlets. See power strip compliance information above
- Dimensions: 27.25” length, 4.32” width, 8.37” height
Agilia Duo*
Your Ally in Power Cord Management
Connect and power Agilia Infusion Pumps
- Lock two Agilia Infusion pumps together
- Transport Agilia Infusion pumps
- Secure to an IV Pole, bed, or gurney**
Reduce number of electrical cords and outlets
- Centralizes the power of two pumps, keeping the pumps plugged in and charged at all times
The Agilia Duo should be utilized under specified operational, storage and transport conditions to ensure its proper performance and users must adhere to the IFU.
Refer to instructions for use for a list of warnings and precautions associated with the device here.
*The Agilia Duo is intended to be used with Agilia large volume and syringe pumps.
**Only single pumps can be attached to a bed rail or gurney rail
Resources
Download the latest IV stands brochure and Agilia Duo brochure below.
DOWNLOAD Rolling IV Stands Brochure ->
DOWNLOAD Agilia Duo Brochure ->
Contact Us
For more information contact your sales representative or call customer service at 855-354-6387
